SMP接线端子系列是中逸光为客户提供的高可靠性AC/DC接线式电源模块。该系列电源具有全球输入电压范围、交直流两用、低功耗、高效率、高可靠性、安全隔离等优点。产品安全可靠，抗浪涌性能优越，EMC 及安全规格满足IEC/EN61000-4、CISPR22/EN55022、UL60950 、EN60950等标准。
展开查看更多
机壳型电源
产品中心
半灌胶SMP系列
点击展开条件搜索框
| 系列标题 | 功率 (W) | 输入电压 (VAC) | 输入电压 (VDC) | 输出电压 (VDC) | 输出电流 | 效率% | 隔离电压 (VAC) | 封装尺寸 (mm) | 资料下载 (3D/PCB封装库/原理图库) | 认证/标准 | 技术手册 | 样品申请 |
| SMP220-SXX | 220 | 90-264 | 展开 | 3.3/5/12/15/24/36/48 | 4.58-44 | 89-94 | 3000 | 140.0*68.0*35.5 | -- -- | -- |  -- |  -- |
| SMP220-S03 | 145.2 | 90-264 | -- | 3.3 | 44 | 89 | 3000 | 140.0*68.0*35.5 | -- | | | |
| SMP220-S05 | 220 | 90-264 | -- | 5 | 44 | 91 | 3000 | 140.0*68.0*35.5 | -- | | | |
| SMP220-S12 | 220 | 90-264 | -- | 12 | 18.33 | 93 | 3000 | 140.0*68.0*35.5 | -- | | | |
| SMP220-S15 | 220 | 90-264 | -- | 15 | 14.66 | 94 | 3000 | 140.0*68.0*35.5 | -- | | | |
| SMP220-S24 | 220 | 90-264 | -- | 24 | 9.16 | 94 | 3000 | 140.0*68.0*35.5 | -- | | | |
| SMP220-S36 | 220 | 90-264 | -- | 36 | 6.11 | 94 | 3000 | 140.0*68.0*35.5 | -- | | | |
| SMP220-S48 | 220 | 90-264 | -- | 48 | 4.58 | 94 | 3000 | 140.0*68.0*35.5 | -- | | | |
| SMP350-SXX | 350 | 90-305 | 展开 | 5/12/24/28/36/48 | 7.29-60 | 90-94 | 3000 | 220.0*68.0*35.0 | -- -- | -- | -- | -- |
| SMP350-S05 | 300 | 90-305 | -- | 5 | 60 | 90 | 3000 | 220.0*68.0*35.0 | -- | | | |
| SMP350-S12 | 350 | 90-305 | -- | 12 | 29.1 | 93 | 3000 | 220.0*68.0*35.0 | -- | | | |
| SMP350-S24 | 350 | 90-305 | -- | 24 | 14.6 | 93 | 3000 | 220.0*68.0*35.0 | -- | | | |
| SMP350-S28 | 350 | 90-305 | -- | 28 | 12.5 | 93 | 3000 | 220.0*68.0*35.0 | -- | | | |
| SMP350-S36 | 350 | 90-305 | -- | 36 | 9.72 | 94 | 3000 | 220.0*68.0*35.0 | -- | | | |
| SMP350-S48 | 350 | 90-305 | -- | 48 | 7.29 | 94 | 3000 | 220.0*68.0*35.0 | -- | | | |
| SMP500-SXX | 500 | 90-305 | 展开 | 5/12/24/36/48/80 | 6.25-80 | 90-95 | 3000 | 232.0*81.0*31.0 | -- -- | -- | -- | -- |
| SMP500-S05 | 400 | 90-305 | -- | 5 | 80 | 90 | 3000 | 232.0*81.0*31.0 | -- | | | |
| SMP500-S12 | 500 | 90-305 | -- | 12 | 41.7 | 94 | 3000 | 232.0*81.0*31.0 | -- | | | |
| SMP500-S24 | 501 | 90-305 | -- | 24 | 20.9 | 94.5 | 3000 | 232.0*81.0*31.0 | -- | | | |
| SMP500-S36 | 500 | 90-305 | -- | 36 | 13.9 | 95 | 3000 | 232.0*81.0*31.0 | -- | | | |
| SMP500-S48 | 501 | 90-305 | -- | 48 | 10.45 | 95 | 3000 | 232.0*81.0*31.0 | -- | | | |
| SMP500-S80 | 500 | 90-305 | -- | 80 | 6.25 | 95 | 3000 | 232.0*81.0*31.0 | -- | | | |
| SMP1000-SXX | 1000 | 90-264 | 250-370 | 12/24/36/48/80 | 12.5-80 | 94-95 | 3000 | 240.0*115.0*41.0 | -- -- | -- | -- | -- |
| SMP1000-S12 | 960 | 90-264 | 250-370 | 12 | 80 | 94 | 3000 | 240.0*115.0*41.0 | -- | | | |
| SMP1000-S24 | 1000 | 90-264 | 250-370 | 24 | 42 | 95 | 3000 | 240.0*115.0*41.0 | -- | | | |
| SMP1000-S36 | 1000 | 90-264 | 250-370 | 36 | 28 | 95 | 3000 | 240.0*115.0*41.0 | -- | | | |
| SMP1000-S48 | 1000 | 90-264 | 250-370 | 48 | 21 | 95 | 3000 | 240.0*115.0*41.0 | -- | | | |
| SMP1000-S80 | 1000 | 90-264 | 250-370 | 80 | 12.5 | 95 | 3000 | 240.0*115.0*41.0 | -- | | |
